MAP1100 Section-14 RMC LPAR Objects

About this task

Note: If the Large File Transfer (the 10th System Check Type status from the top) is FAILED, this System Check Type cannot be displayed.

Procedure

  1. Figure 1 is an example of the detail window for the RMC LPAR objects (in this example, an error condition is not shown).
    Figure 1. Window: RMC LPAR object details
    Window: RMC LPAR object details
  2. Description: A code internal communication problem has occurred.
  3. Action: Contact your next level of support. The next level of support must remotely connect to repair this condition.
  4. Next level of support only: The code checks for any communication problems when trying to access the following objects:
    • IBM.EssStorageFacilityImage
    • IBM.Essserver
    • IBM.EssserverPartition
    • IBM.EssManagementServer
    The details view indicates the location of the problem.
